Material & size:
The standard material are SS304, SS304L, SS316, SS316L. Special Alloy Steel Hastelloy C-276, Monel 400, Inconel, SS904, SS904L, Duplex steel 2205 2507 are acceptable based on customer’s requirement.
The standard sizes are 500*1000mm, 600*1200mm, 1000*1000mm, 1200*1500mm, any size within above range can be customized according to the customer's requirement.
Technical Details
| Model |
Filter Rating(u) |
Structure |
Thickness(mm) |
Weight(kg/m2) |
Porosity(%) |
| H4-2.0T |
2-200 |
30+Filter layer+30+φ4x5Px1.0T |
2.0 |
6.7 |
57 |
| H4-2.5T |
2-200 |
30+Filter layer+30+φ5x7Px1.5T |
2.5 |
9.8 |
50 |
| H5-3.0T |
2-200 |
60+Filter layer+60++20+φ6x8Px2.0T |
3.0 |
11.8 |
50 |
| H5-3.5T |
2-200 |
20+Filter layer+20+10+φ8x10Px2.0T |
3.5 |
12.6 |
54 |
| H5-4.0T |
2-200 |
20+Filter layer+20+10+φ8x10Px2.5T |
4.0 |
14.2 |
55 |
| H5-4.3T |
5-200 |
20+Filter layer+20+10+φ10x13Px3.0T |
4.3 |
16.9 |
50 |
| H5-5.3T |
5-200 |
20+Filter layer+20+10+φ10x13Px4.0T |
5.3 |
20.6 |
51 |
Application:
widely used in chemical fiber, petroleum, chemical industry, pharmacy, foodstuff, water treatment electric, power, pharmaceutics, machinery, metallurgy, ceramics, dispose of sewage, foodstuff and beverage, cosmetic
