12m to 18m Automatic Walking Spider Man Lift Hydraulic Towable Boom Lift

Scissor Lift Platform Description

Product Description:
Self propelled Boom Lift is a perfect combination of simple truck and aerial lift. So self propelled boom lift also have a nickname that is freely drivable aerial lift. Operator can drive the self propelled boom lift for long distance which guarantees the wide range of application. With articulated arm structure, articulated boom lift can't only reach vertical high places but also reach horizontal high places. Furthermore, 360° rotation function enlarging the working range greatly. High strength strong support legs guarantee the absolutely working stability.
The main products of Lifeng lift company are: mobile, fixed, truck type, folding arm type, traction type, guide rail type, cylinder type, chain type, aluminum alloy type, hydraulic loading bridge, aerial work platform and other ten series more than 100 varieties,our company can also according to the special requirements of users, specially designed and produced.

Three kinds of Power:
1.Diesel
2.Battery

Safety Precautions:
1. Explosion-proof valves: protect hydraulic pipe, anti-hydraulic pipe rupture.
2. Spillover valve: It can prevent high pressure when the machine moves up. Adjust the pressure.
3. Emergency decline valve: it can go down when you meet an emergency or the power off.
4. Anti-dropping device: Prevent falling of platform

Model Type	ANJUN-10A Articulated	ANJUN-12A Articulated	ANJUN-14A Telescopic	ANJUN-16A Telescopic
Lifting height	10M	12M	14M	16M
Working height	12M	14M	16M	18M
Load capacity	200KG
Platform size	0.9*0.7M
Working radius	5M	6.5M	8M	10.5M
Net Weight	1855KG	2050KG	2500KG	2800KG
Overall Size( LWH)	6.651.62.05M	7.751.72.2M	6.51.72.2M	71.72.2M
Wind Resistance Level	<=5
20'/40' Container Loading Quantity	20'/1set 40'/2sets	20'/1set 40'/2sets	40'/1set 40'/2sets	40'/1set 40'/2sets

If you want to know more specifications, please get a quote!

Scissor Lift Platform Feature

1.360 degrees rotation of the arm
2.With four full-automatic hydraulic legs. It can be more stable.
3.Sealing parts use the JapanNOK brand, guarantee that the products run 300,000 times without leakage or damage
4.Cylinder outlet is equipped with automatic shut-off valve
5.Equipped with emergency dropping device
6.The machine has two sets of control system, one on the machine, one on the floor, easy and convenient to operate, safe and flexible
7.The rotating parts are equipped with lubricated bearing and grease cup,flexible rotation without noise
8.Equipped with sliding track rollers, reducing the rocking and vibration and ensures the smooth up-down

Scissor Lift Platform Application

Suitable for a wide range of operations such as airport terminals, stations, wharfs, shopping malls, stadiums, residential properties, factories and mines.
