direct discharge grading screen
 Straight Screen Equipment
Sieving Machine
direct discharge grading screen
 Straight Screen Equipment
Sieving Machine

Low Energy Consumption And High Output Straight Screen Equipment

Place of Origin:
Henan,China
Function
Screening separation sorting sieving
Motor
Vertical Vibrating Motor
Sizes
Customized
Share With:
Straight Row Vibrating Screen Description

Direct discharge grading screen from China

Straight row vibrating screen, widely known as "safety officer", It is connected to the production system and the automatic sorting speed is much faster than other types of sieving machines. It adopts high frequency vibration motor as excitation source. After the material enters the screen machine, it is subjected to three-dimensional rotary motion on the screen surface by the vibration source force. Powder and agglomeration are fully dispersed and rapidly separated. Qualified materials enter the lower chamber, and foreign bodies and large particles are discharged to the slag discharge port.

Working Principle
The vibrating motor utilizes two sets unbalanced eccentric blocks to convert the rotary motion of vibrating motor into the
resultant force with horizontal direction, vertical direction and inclined direction. Then, the vibrating motor conveys the power to screen surface and achieves the purpose of screening. The machine can change the power and the trajectory of raw material through change the phase angle and the weight of the eccentric block.
Straight Row Vibrating Screen Feature
1.  All stainless steel design, beautiful and durable appearance.
 2.  It is small, does not take up space, and is easy to move.
 3.  Low energy consumption and high efficiency.
 4.  It is convenient to disassemble and assemble, easy to clean inside and outside, no sanitary dead space, and complies with food grade GMP specifications.
 5.  Automatic operation, continuous production for 24 hours.
 6.  Ultra low mute design.
 7.  Tight sealing, no liquid leakage, no dust flying.
 8.  It can be used in single layer or multiple layers, and can be filtered in multiple levels at one time.
Straight Row Vibrating Screen Application
It is mainly used for coarse screening and precise screening of granular powder in flour, starch, washing powder, metal powder,additives, chemical industry, non mineral industries, etc., with large processing capacity and easy integration with production lines. It can be selected from 600MM to 1800MM.
